WHAT’S INCLUDED?
One SI/Katana-R Night Vision Goggle; four lens caps; Steele Industries hard case; warranty card; quality control report; spec sheets.
TUBE SPECS
Our SI/Katana-R Goggle is offered in various image intensifier options:
ELBIT COMM-SPEC THIN FILMED WHITE PHOSPHOR
- Commercial Spec Image Intensifier
- Auto-Gated
- Thin-Filmed Technology
The commercial spec Elbit option is great for those who are on a tighter budget or simply do not want to drop the additional money required for a mil-spec tube. This option will still give you Gen 3 performance which is sure to impress! This option will give a MINIMUM FOM of 1,536 but in many cases exceeds this value.
ELBIT MIL-SPEC THIN FILMED WHITE PHOSPHOR
- Mil-Spec Image Intensifier
- Auto-Gated
- Thin-Filmed Technology
The mil-spec Elbit options benefit from stricter requirements on spots allowed, specs, and more. These options are great for those that desire mil-spec performance but still wish to take advantage of the savings associated with Elbit image intensifiers. There are two options available, a 1,600 and 2,000 minimum FOM. This adds another layer of refinement for the consumer in regards to tube selection.
L3 UNFILMED WHITE PHOSPHOR
- Unfilmed Technology
- Aviation Spot Tolerances
- Auto-Gated
The L3Harris tubes are held to an aviation spot tolerance which is the strictest available. On top of that, they are held to military spec requirements to ensure each tube conforms to a variety of performance metrics. For those that desire to experience the advantage associated with unfilmed technology, it is now possible at various budgets levels thanks to our multiple minimum FOM options. Whether you’re on a tighter budget that lends itself to a 1,500 minimum FOM, a higher end budget that affords you the opportunity to acquire a 2,400+ FOM tube, or somewhere in between, there is an option for you.
SPECIFICATIONS
Features:
- CNC machined 7075-T6 & 6061-T6 aerospace grade aluminum, aerospace Grade 4 Titanium.
- Articulating pods
- Pod Power Off when individually articulated
- IP68+ Rated
- C123 Battery Configuration
- 10 year warranty and limited lifetime service
Assembled in house with our accredited ISO 9001:2015 process and procedures
TECHNICAL SPECIFICATIONS
| Field of View | 40° |
| Magnification | 1x |
| Diopter Adjustment | -6 to +2 Diopters |
| Eye Relief | 25mm |
| Submersible | IP68+ |
| Objective Lens | 27mm, f/1.2 |
| Focus Range | 9.8″ to infinity |
| Power Source | 1 C123 Size Battery |
| Operation Time | 40+ hours |
| Weight | 530.98 g (18.73 oz) |
