Description
RICO MICRO RH25 640 12 Micron 25mm Multi-Purpose Monocular – Headmountable, Clip-on and Weapon Mountable
The RICO MICRO Series is an advanced electro-optic device miniaturized to deliver remarkably versatile functionality: Handheld, helmet mount, weapon mount, and clip-on. Weighing less than a pound, the MICRO will fit in the palm of your hand and can be used with standard dovetail helmet mounts or rifle-mounted as a stand-alone weapon sight. InfiRayOutdoor is blazing a new trail with features never-before-seen in a helmet-mounted thermal, such as onboard recording, onboard video play-back, and a high definition AMOLED display. The RH25 also features InfiRay’s latest high-performance 640×512, 12 μm sensor technology, MATRIX III processing, and a manual-focus f/1.0 objective lens to create an image that is unlike anything in its class.
InfiRay Outdoor’s cutting edge manufacturing techniques and the highest-quality components on the market combine to produce an optic that is a step ahead of the competition in size, weight, and performance. The RICO MICRO has the features night hunters want and is more capable than optics twice the price and twice the size.
-
Display
Display Type
AMOLED
Wifi
Yes
Onboard Recording
Yes
Image Capture
Yes
Video Output
Analog RS-170/NTSC
Warranty
5-Years
Country of Manufacture
China
Recoil Rating
1000 g/s² (300 Win./7mm Mag)
Ingress Protection
IP67
-
Environmental Specifications
Run Time
4 Hours
Power Source
18650 Rechargeable
Operating Temperature Range
-4°F to 122°F
-
Lens Specifications
Optical Magnification
1X
Digital Magnification
4X
Objective Lens Material
Germanium
Horizontal Angular Field of View
17.5°
Vertical Angular Field of View
14°
Detection Range
1375 Yards
Objective Focal Length
25mm
Objective Diameter
25mm
Objective F#
1.0
Focusing Mechanism
Manual
Reticle
7 Types
Connector Type
“Data Cable with USB, BNC, and 7-Pin Connectors”
Connector Output
Analog
Eye Relief
35mm
Diopter Range
-4 to +4
Startup Time
<10 Seconds, Instant from Standby
Housing Material
Aluminum
-
Sensor Specifications
Device Technology
Thermal Imaging
Sensor Type
iRay Micro II Thermal Sensor
Sensor Resolution
640×512
Spectral Response
8-12μm
Sensor Frame Rate
50Hz
Sensor Pixel Size
12μm
Thermal Sensitivity
<40mk
